• Test Leader / Other

  • ( Alligator Clip / 1KV )

    BP-276N ( Alligator Clip / 1KV ) Test Leader / Other

    Alligator clip UL 1000V CAT III Max. Current : 10A Meet IEC-1010-1, UL-3111-1

    More

  • ( Scope Probe Into DMM Converter )

    PL-10N ( Scope Probe Into DMM Converter ) Test Leader / Other

    MODEL：PL-10N IMPEDANCE：1.111MΩ ACCURACY：±0.5% FREQUENCY B.W.：DC~50MHz WORKING POWER：MAX. 1Watt INPUT VOLTAGE：MAX.250VDC or 200V rms AC DIMENSION：48mm(L)xΦ16mm(D) WEIGHT：25g APPLICATION：Matching the impedance of the Scope probe with the DMM. wiht this converter, the user can use the oscilloscope to watch the wave from and measure the precise reading from the DMM.Note:PL-10N is the latest improved produ...

    More

  • ( Scope Probe Into DMM Converter )

    PL-10 ( Scope Probe Into DMM Converter ) Test Leader / Other

    MODEL：PL-10   IMPEDANCE：1.12MΩ   ACCURACY：±0.5%   FREQUENCY B.W.：DC~50MHz   WORKING POWER：MAX. 1Watt   INPUT VOLTAGE：MAX.250VDC or 200V rms AC   DIMENSION：46mm(L)xΦ16mm(D)  WEIGHT：25g   APPLICATION：Matching the impedance of the Scope probe with the DMM. wiht this converter, the user can use the oscilloscope to watch the wave from and...

    More

  • ( 50Ω Load / 2 Watt )

    PL-50N ( 50Ω Load / 2 Watt ) Test Leader / Other

    IMPEDANCE：50Ω Z-TOL：±0.5Ω FREQUENCE B.W.：DC TO 1 GHz WORKING POWER：2 WATT DIMENSION：48mm(L)x16mm(D) WEIGHT：25gNote：PL-50N is the improved model. It is using gold plate to preventing oxidization and also using beryllium copper on the BNC to lower the contact resistance and increase the durability and contact life.

    More

  • ( 50Ω / Best VSWR )

    PL-50Pro ( 50Ω / Best VSWR ) Test Leader / Other

    IMPEDANCE：50Ω Z-TOL：±１％ FREQUENCE B.W.：DC TO 1 GHz WORKING POWER：１ WATT Best VSWR Model. ＜1.1 DC~1GHzNote：PL-50N is the improved model. It is using gold plate to preventing oxidization and also using beryllium copper on the BNC to lower the contact resistance and increase the durability and contact life.

    More

  • ( 75Ω Load / 1 Watt )

    PL-75 ( 75Ω Load / 1 Watt ) Test Leader / Other

    Feature It is able to provide the best impedance matching when using RG-59/U as transmissionequipment to connect to oscilloscopes.

    More

  • ( 93Ω Load / 1 Watt )

    PL-93 ( 93Ω Load / 1 Watt ) Test Leader / Other

    Feature It has 93Ω impedance feature when using RG-62 coaxial cable as transmission equipment.PL-93 will provide best waveforms when connecting to oscilloscopes.

    More

  • ( BNC connects to the specialized adapter of the banana plug )

    MT-246N ( BNC connects to the specialized adapter of the banana plug ) Test Leader / Other

    BNC connects to the specialized adapter of the banana plug. PL-10 exclusive accessory Red and Black plastic isolation cover are convenient to recognize positive and negative electrodes  The end of banana plug uses beryllium copper to prevent bad connection Accord with CE norm. It is safe and reliable. The maximum working voltage 300V CAT2. 3A.1GHz. Length: 70mm.  Width: 28mm.  Weight: 19g.

    More

  • ( Combination type test lead terminal )

    BP-286N ( Combination type test lead terminal ) Test Leader / Other

    Combination Type terminal of test lead. Connect to BP-356N can be used as the test lead of DMM or the test lead of Differential Probe. Meet the regulation of CAT III,  1000V / 10A / UL-94V-2 New movable isolated terminal. Can be inserted into banana socket or the fixed type test terminal to get the good connection. Connect 2 pcs to make a long test probe convenience to for the far away test point measurement. ...

    More

  • ( LCR Meter Accessory )

    RP-91 ( LCR Meter Accessory ) Test Leader / Other

    PINTEK LCR-900 standard accessory Compatible on all brands bench type LCR meter. 4-wire leads alligator clip compensates internal impedance error.

    More

Total of 22 results
